31
G. SWING-AWAY FOOTRESTS
Note
: Footrests and legrests are interchangeable and will fit on left or right side of chair.
Appropriate functional use will require additional adjustment to footrest
(p.32 Changing Footrest from Left to Right)
1. Installation
a. Place right footrest on the 2-pin hanger plate
offset to the outside of the frame.
Make sure the holes on foot rest bracket
are well seated over both
mounting posts.
b. Swing footrest toward inside of
chair until it locks into place.
c. See release lever positioning below
to change position of lever to accommodate
the user or caregiver.
d. Repeat steps a - b for left footrest.
2. Removal
a. Activate release lever of right footrest
pushing it toward outside of chair.
b. Swing footrest towards outside of chair.
c. Lift legrest off mounting posts.
d. Repeat steps e - g for left footrest.
continued on page 32
30
F. DETACHABLE ARMRESTS
1. Installation
a. Align right arm over receiver tubes on
side frame.
b. Push down on armrest until detent is
engaged.
c. Pull up firmly to ensure that the
armrest is engaged.
d. Repeat steps a-c for left armrest.
2. Removal
a. Press in on detent button located on
the right armrest.
b. Holding the armrest in the center, pull
up on arm rest until it is free of the
receiver tubes.
c. Repeat steps e & f for left armrest.
Note: When removing armrest be sure to pull
straight up to prevent armrest tubes from
becoming wedged in receivers.
To correct this problem push armrest back
down into place and repeat the process,
emphasizing on pulling upward with a
straight and even motion.
X . S E T U P & A D J U S T M E N T X . S E T U P & A D J U S T M E N T
