REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-520GS/520GST/520GST9
7-8
(d)
C509 1-126-941-11 ELECT 470
µ
F 20% 25V
C510 1-137-368-11 FILM 0.0047
µ
F 5% 50V
C511 1-110-641-51 ELECT 33
µ
F 20% 200V
C512 1-107-889-11 ELECT 220
µ
F 20% 25V
C513 1-163-017-00 CERAMIC CHIP 0.0047
µ
F 10% 50V
C514 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C515 1-107-889-11 ELECT 220
µ
F 20% 25V
C516 1-130-495-00 FILM 0.1
µ
F 5% 50V
C517 1-104-574-11 CERAMIC 0.0047
µ
F 10% 2KV
C518 1-117-413-11 FILM 6000pF 3% 1.8KV
C519 1-107-444-11 CERAMIC 100pF 5% 2KV
C520 1-136-553-11 FILM 0.0015
µ
F 5% 630V
C521 1-107-597-11 CERAMIC 22pF 5% 500V
C522 1-107-444-11 CERAMIC 100pF 5% 2KV
C523 1-137-370-11 FILM 0.01
µ
F 5% 50V
C524 1-113-694-11 FILM 0.056
µ
F 5% 250V
C525 1-107-846-11 FILM 0.1
µ
F 5% 250V
C526 1-115-514-11 FILM 0.22
µ
F 5% 250V
C527 1-115-517-11 FILM 0.39
µ
F 5% 250V
C528 1-115-521-11 FILM 0.82
µ
F 5% 250V
C529 1-107-683-11 ELECT 2.2
µ
F 0 250V
C530 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C531 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C532 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C533 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C534 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C535 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C536 1-128-526-11 ELECT 100
µ
F 20% 25V
C537 1-115-523-21 FILM 1.2
µ
F 5% 250V
C538 1-117-958-11 FILM 0.24
µ
F 5% 400V
C539 1-107-960-11 ELECT 4.7
µ
F 20% 250V
C540 1-106-343-00 MYLAR 0.001
µ
F 10% 200V
C541 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C542 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C544 1-137-368-11 FILM 0.0047
µ
F 5% 50V
C545 1-126-967-11 ELECT 47
µ
F 20% 50V
C547 1-126-967-11 ELECT 47
µ
F 20% 50V
C549 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C550 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C551 1-163-009-11 CERAMIC CHIP 0.001
µ
F 10% 50V
C553 1-126-963-11 ELECT 4.7
µ
F 20% 50V
C554 1-163-037-11 CERAMIC CHIP 0.022 µ F 10% 50V
C555 1-163-037-11 CERAMIC CHIP 0.022
µ
F 10% 50V
C556 1-163-009-11 CERAMIC CHIP 0.001
µ
F 10% 50V
C557 1-115-185-11 CERAMIC CHIP 0.033
µ
F 10% 50V
C559 1-162-134-11 CERAMIC 470pF 10% 2KV
C561 1-137-194-81 FILM 0.47
µ
F 5% 50V
C562 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C563 1-117-214-11 CERAMIC 0.001
µ
F 10% 2KV
C564 1-126-963-11 ELECT 4.7
µ
F 20% 50V
C666 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C667 1-126-967-11 ELECT 47
µ
F 20% 50V
C701 1-126-967-11 ELECT 47
µ
F 20% 50V
C702 1-130-495-00 FILM 0.1
µ
F 5% 50V
C705 1-126-942-61 ELECT 1000
µ
F 20% 25V
C706 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C707 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C709 1-130-495-00 FILM 0.1
µ
F 5% 50V
C710 1-163-019-00 CERAMIC CHIP 0.0068
µ
F 10% 50V
C711 1-107-894-11 ELECT 220
µ
F 20% 35V
C712 1-106-228-00 MYLAR 0.22
µ
F 10% 100V
C713 1-126-942-61 ELECT 1000
µ
F 20% 25V
C714 1-126-967-11 ELECT 47
µ
F 20% 50V
C715 1-107-932-11 ELECT 47
µ
F 20% 100V
C717 1-107-930-91 ELECT 22
µ
F 20% 100V
C729 1-162-134-11 CERAMIC 470pF 10% 2KV
C735 1-130-495-00 FILM 0.1
µ
F 5% 50V
C746 1-163-009-11 CERAMIC CHIP 0.001
µ
F 10% 50V
C747 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C750 1-126-964-11 ELECT 10
µ
F 20% 50V
C751 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C901 1-107-889-11 ELECT 220
µ
F 20% 25V
C902 1-163-809-11 CERAMIC CHIP 0.047
µ
F 10% 25V
C903 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C904 1-137-605-11 FILM 0.01
µ
F 10% 250V
C905 1-104-653-11 ELECT 220
µ
F 20% 16V
C906 1-106-220-00 MYLAR 0.1
µ
F 10% 100V
C907 1-110-641-51 ELECT 33
µ
F 20% 200V
C908 1-136-169-00 FILM 0.22
µ
F 5% 50V
C909 1-106-355-12 MYLAR 0.0033
µ
F 10% 200V
C910 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C911 1-163-275-11 CERAMIC CHIP 0.001
µ
F 5% 50V
C912 1-163-275-11 CERAMIC CHIP 0.001
µ
F 5% 50V
C913 1-164-004-11 CERAMIC CHIP 0.1
µ
F 10% 25V
C914 1-163-275-11 CERAMIC CHIP 0.001
µ
F 5% 50V
C915 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C916 1-136-064-00 FILM 2200pF 3% 1.2KV
C917 1-107-889-11 ELECT 220
µ
F 20% 25V
C919 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C920 1-163-009-11 CERAMIC CHIP 0.001
µ
F 10% 50V
C921 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C922 1-117-665-11 FILM 0.33
µ
F 5% 200V
C923 1-106-359-00 MYLAR 0.0047
µ
F 10% 100V
C924 1-106-220-00 MYLAR 0.1
µ
F 10% 100V
C925 1-137-372-11 FILM 0.022
µ
F 5% 50V
C926 1-106-228-00 MYLAR 0.22
µ
F 10% 100V
C927 1-107-903-11 ELECT 2.2
µ
F 20% 50V
C928 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C929 1-128-526-11 ELECT 100
µ
F 20% 25V
C930 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C931 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C945 1-107-909-11 ELECT 47
µ
F 20% 50V
C1003 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C1004 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C1005 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C1007 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C1008 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C1009 1-126-960-11 ELECT 1
µ
F 20% 50V
C1501 1-163-021-91 CERAMIC CHIP 0.01
µ
F 10% 50V
C1502 1-117-722-11 ELECT 2200
µ
F 20% 10V
C1503 1-163-001-11 CERAMIC CHIP 220pF 10% 50V
