REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-520GS/520GST/520GST9
7-2
(a2)
C448
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C450
1-163-235-11 CERAMIC CHIP 22pF
5%
50V
C451
1-104-664-11 ELECT
47
µ
F
20% 25V
C452
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C453
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C454
1-104-665-11 ELECT
100
µ
F
20% 25V
C455
1-163-243-11 CERAMIC CHIP 47pF
5%
50V
C457
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C460
1-162-318-11 CERAMIC
0.001
µ
F
10% 500V
C461
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C463
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C464
1-107-906-11 ELECT
10
µ
F
20% 50V
C465
1-107-906-11 ELECT
10
µ
F
20% 50V
C466
1-126-964-11 ELECT
10
µ
F
20% 50V
C467
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C468
1-126-964-11 ELECT
10
µ
F
20% 50V
C469
1-126-964-11 ELECT
10
µ
F
20% 50V
C470
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C471
1-162-318-11 CERAMIC
0.001
µ
F
10% 500V
C478
1-115-350-51 CERAMIC
0.0047
µ
F
2KV
C479
1-163-133-00 CERAMIC CHIP 470pF
5%
50V
C480
1-104-665-11 ELECT
100
µ
F
20% 25V
C481
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C482
1-115-339-11 CERAMIC CHIP 0.1
µ
F
10% 50V
C483
1-115-339-11 CERAMIC CHIP 0.1
µ
F
10% 50V
C484
1-162-318-11 CERAMIC
0.001
µ
F
10% 500V
C485
1-107-652-11 ELECT
10
µ
F
20% 250V
C486
1-163-021-91 CERAMIC CHIP 0.01
µ
F
10% 50V
C487
1-126-964-11 ELECT
10
µ
F
20% 50V
C489
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
C497
1-164-004-11 CERAMIC CHIP 0.1
µ
F
10% 25V
CN401*1-564-521-11 PLUG, CONNECTOR 6P
CN402*1-564-522-11 PLUG, CONNECTOR 7P
CN403*1-564-523-11 PLUG, CONNECTOR 8P
CN405*1-564-524-11 PLUG, CONNECTOR 9P
CN406*1-766-179-11 PIN, CONNECTOR (PC BOARD) 2P
CN407*1-564-522-11 PLUG, CONNECTOR 7P
D101
8-719-062-51 DIODE 1PS226-115
D102
8-719-062-51 DIODE 1PS226-115
D103
8-719-404-50 DIODE MA111-TX
D104
8-719-052-12 DIODE 1SS376TE-17
D105
8-719-052-12 DIODE 1SS376TE-17
D106
8-719-052-12 DIODE 1SS376TE-17
D107
8-719-052-12 DIODE 1SS376TE-17
D201
8-719-062-51 DIODE 1PS226-115
D202
8-719-062-51 DIODE 1PS226-115
D203
8-719-404-50 DIODE MA111-TX
D204
8-719-052-12 DIODE 1SS376TE-17
D205
8-719-052-12 DIODE 1SS376TE-17
D206
8-719-052-12 DIODE 1SS376TE-17
D207
8-719-052-12 DIODE 1SS376TE-17
D301
8-719-062-51 DIODE 1PS226-115
D302
8-719-062-51 DIODE 1PS226-115
D303
8-719-404-50 DIODE MA111-TX
D304
8-719-052-12 DIODE 1SS376TE-17
D305
8-719-052-12 DIODE 1SS376TE-17
D306
8-719-052-12 DIODE 1SS376TE-17
D307
8-719-052-12 DIODE 1SS376TE-17
D401
8-719-404-50 DIODE MA111-TX
D404
8-719-052-12 DIODE 1SS376TE-17
D405
8-719-404-50 DIODE MA111-TX
D406
8-719-404-50 DIODE MA111-TX
D407
8-719-404-50 DIODE MA111-TX
D408
8-719-404-50 DIODE MA111-TX
D409
8-719-404-50 DIODE MA111-TX
D410
8-719-404-50 DIODE MA111-TX
FB101 1-216-295-91 SHORT
0
FB201 1-216-295-91 SHORT
0
FB301 1-216-295-91 SHORT
0
FB402 1-412-529-11 INDUCTOR
22
µ
H
FB403 1-412-911-31 FERRITE
1.1
µ
H
FB405 1-412-911-31 FERRITE
1.1
µ
H
FB406 1-412-911-31 FERRITE
1.1
µ
H
IC401 8-759-522-86 IC M52755FP-TP
IC402 8-759-542-30 IC MM1383XD
IC403 8-749-013-90 IC VPS13
IC404 8-759-566-26 IC LSC4380DW2AR2
IC406 8-759-701-79 IC NJM7812FA
IC408 8-759-239-14 IC TA78L05S
IC409 8-759-502-82 IC LM324M
IC410 8-759-635-27 IC M62352GP-75E
IC413 8-759-082-57 IC TC7W04FU
L101
1-414-137-31 INDUCTOR
0.22
µ
H
L102
1-414-137-31 INDUCTOR
0.22
µ
H
L201
1-414-137-31 INDUCTOR
0.22
µ
H
L202
1-414-137-31 INDUCTOR
0.22
µ
H
L301
1-414-137-31 INDUCTOR
0.22
µ
H
L302
1-414-137-31 INDUCTOR
0.22
µ
H
L303
1-408-603-31 INDUCTOR
10
µ
H
L401
1-408-615-31 INDUCTOR
100
µ
H
L402
1-412-963-11 INDUCTOR
100
µ
H
PS401
!
1-533-590-31LINK, IC (1A/90V AC, 60V DC)
