REF.NO.
PART NO.
DESCRIPTION
REMARK
REF.NO.
PART NO.
DESCRIPTION
REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-520GS/520GST/520GST9
7-5
(g)
C601
!
1-113-900-51 CERAMIC
470pF
10% 250V
C602
!
1-113-900-51 CERAMIC
470pF
10% 250V
C603
!
1-107-533-51 FILM
1
µ
F
20% 250V
C604
!
1-107-533-51 FILM
1
µ
F
20% 250V
C605
!
1-113-926-91 CERAMIC
0.0047
µ
F
250V
C606
!
1-113-926-91 CERAMIC
0.0047
µ
F
250V
C610
1-137-479-11 FILM
1
µ
F
10% 400V
C611
1-113-707-11 ELECT(BLOCK) 220
µ
F
20% 450V
C616
1-104-664-11 ELECT
47
µ
F
20% 25V
C621
1-136-205-11 FILM
0.022
µ
F
10% 630V
C640
1-104-330-91 CERAMIC
470pF
10% 1KV
C641
1-104-330-91 CERAMIC
470pF
10% 1KV
C642
1-136-169-00 FILM
0.22
µ
F
5%
50V
C643
1-136-169-00 FILM
0.22
µ
F
5%
50V
C644
1-104-330-91 CERAMIC
470pF
10% 1KV
C645
1-136-165-00 FILM
0.1
µ
F
5%
50V
C646
1-136-165-00 FILM
0.1
µ
F
5%
50V
C647
1-129-718-00 FILM
0.022
µ
F
5%
630V
C660
1-115-779-11 ELECT
120
µ
F
20% 25V
C661
1-126-933-11 ELECT
100
µ
F
20% 16V
C662
1-130-495-00 FILM
0.1
µ
F
5%
50V
C663
1-126-965-11 ELECT
22
µ
F
20% 50V
C670
1-137-370-11 FILM
0.01
µ
F
5%
50V
C671
1-107-955-11 ELECT
100
µ
F
20% 200V
C672
1-107-950-11 ELECT
3.3
µ
F
20% 200V
C673
1-107-935-11 ELECT
330
µ
F
20% 100V
C674
1-107-928-11 ELECT
4.7
µ
F
20% 100V
C675
1-107-890-11 ELECT
2200
µ
F
20% 25V
C676
1-107-888-11 ELECT
47
µ
F
20% 25V
C677
1-107-890-11 ELECT
2200
µ
F
20% 25V
C678
1-107-888-11 ELECT
47
µ
F
20% 25V
C679
1-126-927-11 ELECT
2200
µ
F
20% 10V
C680
1-126-927-11 ELECT
2200
µ
F
20% 10V
C681
1-126-963-11 ELECT
4.7
µ
F
20% 50V
C682
1-126-963-11 ELECT
4.7
µ
F
20% 50V
C683
1-164-646-11 CERAMIC
2200pF
10% 500V
C684
1-137-370-11 FILM
0.01
µ
F
5%
50V
C685
1-126-967-11 ELECT
47
µ
F
20% 50V
C690
1-128-528-11 ELECT
470
µ
F
20% 16V
C691
1-107-888-11 ELECT
47
µ
F
20% 25V
C692
1-115-737-11 ELECT
0.001F
20% 10V
C693
1-130-495-00 FILM
0.1
µ
F
5%
50V
C694
1-107-888-11 ELECT
47
µ
F
20% 25V
CN603*1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
CN604*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN605*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN671*1-764-334-11 PLUG, CONNECTOR 11P
CN672*1-564-512-11 PLUG, CONNECTOR 9P
CN673*1-564-508-11 PLUG, CONNECTOR 5P
D610
!
8-719-510-53 DIODE D4SB60L
D611
8-719-029-04 DIODE D5L60
D612
8-719-304-63 DIODE RM11C
D614
8-719-911-19 DIODE 1SS119-25
D617
8-719-911-19 DIODE 1SS119-25
D640
8-719-911-19 DIODE 1SS119-25
D660
8-719-066-51 DIODE P6KE170AG23
D661
8-719-979-64 DIODE UF4005PKG23
D662
8-719-058-92 DIODE AG01A-V1
D663
8-719-110-31 ZENER DIODE RD12ESB2
D664
8-719-911-19 DIODE 1SS119-25
D665
8-719-110-31 ZENER DIODE RD12ESB2
D666
8-719-109-97 ZENER DIODE RD6.8ESB2
D670
8-719-064-49 DIODE D4SBL40
D671
8-719-510-64 DIODE S2LA20F
D672
8-719-052-91 DIODE D4SBS4-F
D673
8-719-022-97 DIODE D2S4MF
D674
8-719-022-97 DIODE D2S4MF
D677
8-719-911-19 DIODE 1SS119-25
D678
8-719-911-19 DIODE 1SS119-25
D680
8-719-911-19 DIODE 1SS119-25
D681
8-719-911-19 DIODE 1SS119-25
D682
8-719-510-64 DIODE S2LA20F
D683
8-719-911-19 DIODE 1SS119-25
D684
8-719-110-49 ZENER DIODE RD18ESB2
D691
8-719-028-45 DIODE D2L20U
D692
8-719-911-19 DIODE 1SS119-25
F601
!
1-576-233-11 FUSE (H.B.C.) (6.3A/250V)
FB610 1-410-396-71 FERRITE
0.45
µ
H
FB611 1-410-396-71 FERRITE
0.45
µ
H
FB612 1-410-396-71 FERRITE
0.45
µ
H
IC610 8-749-013-77 IC TME757
IC630 8-749-012-49 IC DM-57N
IC660 8-759-469-10 IC TOP223PF1
IC690 8-749-013-76 IC PQ6RD83B
L610
1-416-297-11 COIL, CHOKE
500
µ
H
L611
1-412-529-11 INDUCTOR
22
µ
H
L612
1-412-529-11 INDUCTOR
22
µ
H
L670
1-412-529-11 INDUCTOR
22
µ
H
L671
1-412-529-11 INDUCTOR
22
µ
H
L672
1-412-529-11 INDUCTOR
22
µ
H
L673
1-412-529-11 INDUCTOR
22
µ
H
L691
1-412-529-11 INDUCTOR
22
µ
H
