78
Connections for a Digital Non-Linear Editing System
Ch
apt
er 5
Con
nec
tions
and
S
e
ttin
gs
Settings on the DSR-1800/1800P
For details of video/audio input and audio mode settings,
see “Settings for Recording” on page 25.
REF.
VIDEO
IN SDTI(QSDI)OUT
SDTI(QSDI)
IN
AUDIO
MONITOR OUT VIDEO OUT 2
(SUPER)
B B OUT(1/2/3/4)
QSDI OUTPUT
QSDI INPUT
REMOTE RECORDER
1
1
1
2
1 3
DSR-1800/1800P
(recorder)
ES-7 EditStation
Audio input
Composite
video input
A 75
Ω
coaxial cable (not supplied)
B 9-pin remote control cable
(not supplied)
C Cable with RCA phono plugs
(not supplied)
Video monitor
Button Setting
REMOTE On (lit)
