Gearbox, shafts – Snapper 8245 User Manual
Page 11
11
GEARBOX,
SHAFTS
ITEM
PART
NO.
DESCRIPTION
1*
2-8220
SHAFT, Auger (8245 Models)
-
2-7639
SHAFT, Auger (8265 & 9265 Models)
-
2-9552
SHAFT, Auger (10305E, 11305 & E11305 Models)
2
1-3857
KEY, 1/4 x 7/8" Woodruff
3
5-1305
GEAR,
Worm
4
1-3855
WASHER, 1.0 x 1-1/2" Thrust (2)
5
1-3858
SEAL, 1-1/2” O.D. Oil (2)
6
1-8451
COVER, Gear Case
7
9-0290
SCREW, 1/4-20 x 3/4" Hex Washer Self-Tap (4)
8
1-3854
O-RING, Case Cover
9
1-9674
CASE,
Gear
10
9-0815
SCREW, 3/8-16 x 1/2" Hex Washer Self-Tap
11
2-7630
SHAFT,
Impeller
12
1-3313
BEARING, Impeller Shaft
13
1-3862
PIN, 1/4 x 1-1/2" Roll
14
1-3856
SPACER, Gear Bearing
15
1-3861
KEY, 3/16 x 7/8" Woodruff
16
2-7606
GEAR, Rolled Worm
17
1-0935
WASHER, 3/4 x 1-1/8" Thrust (2)
18
1-2252
BUSHING, Impeller Shaft
19
1-3853
O-RING, Case Cap
20
1-8450
CAP,
Case
21
9-1075
SCREW, #10-24 x 5/8" Hex Washer Self-Tap (3)
*NOTE:
The following assemblies are made
of items 1 through 21 above:
5-3426, 24” Gear Case Assembly
5-7305, 26” Gear Case Assembly
5-7304, 30” Gear Case Assembly
LARGE FRAME SNOWTHROWER
MANUAL No. 06037
