Table of Contents
• Trinitron
is a registered trademark of
Sony Corporation.
• VESA and DDC
are trademarks of the
Video Electronics Standard
Association.
•
E
NERGY
S
TAR is a U.S. registered
mark.
• All other product names mentioned
herein may be the trademarks or
registered trademarks of their respective
companies.
• Furthermore, “
” and “” are not
mentioned in each case in this manual.
EN
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Identifying parts and controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Step 1: Connect your monitor to your computer . . . . . . . . . . . . . . . 5
Step 2: Connect the power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 3: Turn on the monitor and computer . . . . . . . . . . . . . . . . . . . 5
Selecting the on-screen menu language (LANGUAGE) . . . . . . . . . 6
Selecting the input signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Customizing Your Monitor . . . . . . . . . . . . . . . . . . . . . . . .7
Navigating the menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Adjusting the brightness and contrast (CONTRAST/BRIGHT) . . . . 8
Adjusting the centering of the picture (SIZE/CENTER) . . . . . . . . . . 9
Adjusting the size of the picture (SIZE/CENTER) . . . . . . . . . . . . . . 9
Automatically sizing and centering the picture (AUTO) . . . . . . . . . . 9
Adjusting the shape of the picture (GEOMETRY) . . . . . . . . . . . . . 10
Adjusting the convergence (CONVERGENCE) . . . . . . . . . . . . . . . 10
Adjusting the picture quality (SCREEN) . . . . . . . . . . . . . . . . . . . . . 11
Adjusting the color of the picture (COLOR) . . . . . . . . . . . . . . . . . . 12
Additional settings (OPTION) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Resetting the adjustments (RESET) . . . . . . . . . . . . . . . . . . . . . . . 14
Technical Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
If thin lines appear on your screen (damper wires) . . . . . . . . . . . . 15
On-screen messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Trouble symptoms and remedies . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Self-diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
