COMPATIBILITY
• Platform independent - works with PC, OSX, Linux, MAC, Unix
HARWARE FEATURES
• 5 LEDs display Power, US, DS, Online and Link status
• Power supply is DC 12V 1A
• Wall mount
PORTS
• F type female Cable Connection 75ohm
• One Gigabit Ethernet port
• Single External Power Supply
SOFTWARE FEATURES
• GUI displays common troubleshooting information and modem status
• Meets all DOCSIS3.0 requirements
MODULATION
• Downstream: 64QAM, 256QAM
• Upstream: QPSK, 4, 8, 16, 32, 64QAM and 128QAM (SCDMA only)
MAXIMUM DATA RATE
• Downstream: >160Mbps
• Upstream: >40Mbps
BANDWIDTH
• Downstream: 6MHz
• Upstream: 200kHz, 800kHz, 1.6MH, 3.2MHz,6.4MHz
SYMBOL RATE
• Downstream: 64QAM 5.057 Msym/s, 256QAM 5.361 Msym/s
• Upstream:160,320,640,1280, 2560,5120 Ksym/s
OPERATING LEVEL RANGE
• Downstream: -15 to + 20dBmV per channel, <33dBmV Total
• Upstream:
• A-TDMA :
• +17 to +57dBmV (32QAM, 64QAM); (54/51dBmV
less per Channel if 2/more channels are used)
• +17 to +57dBmV (8QAM, 16QAM); (55/52dBmV
less per Channel if 2/more channels are used)
• +17 to +61dBmV (QPSK); (58/55dBmV less per
Channel if 2/more channels are used)
• S-CDMA
• +8 to +56dBmV(53 dBmV less per Channel if
more than 1 channel is used) (all modulations)
CHANNEL BONDING
• Downstream : Up to 4 channels
• Upstream : Up to 4 channels
FREQUENCY RANGE
• Downstream: 5 To 85MHz
• Upstream: 108 To 890MHz
COMPLIANT STANDARD
• Supports CableLabs DOCSIS 1.0/1.1/2.0/3.0
NETWORK INTERFACE
• 10/100/1000 Base-T Ethernet
NETWORK PROTOCOL
• TCP/IP/IPv6/IPv4
• SNMP V1/2/3
ENVIRONMENT
• Operating Temperature: 32 F o (0 C o ) ~104 F o (40 C o )
• Storage Temperature: -22 F o (-30 C o ) ~ 140 F o (80 C o )
• Operating Humidity: 5% to 95% R.H. (Non condensing)
POWER COMSUMPTION
• INPUT DC: 12V DC
REGULATORY COMPLIANT
• FCC CLASS B
• Safety: UL
DIMENSION (L x W x H)
• 151 x 139 x 31 mm
• 5.9 x 5.5 x 1.2 in
WEIGHT
• 2lb (Approximately)
WARRANTY
• Limited Lifetime
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local
country contact information
©2008, SMC Networks. All rights reserved.
www.smc.com
TECH SPECS - SMCD3CM
