10
Mounting to the Windshield
Note: Use only the appropriate XACT accessories or input devices with your receiver. Use only the 12v
Vehicle Adapter that is provided with the kit. It is important that you do not modify it in any way as this
may result in damage to your equipment and void the warranty.
1. Insert the 4 suction cups into
the larger side of the holes
on the Vehicle Mounting
Bracket and slide outward to
lock in place. (figure 1).
2. Slide the XACT Sirius
Satellite Radio Receiver
(figure 2) onto the mounting
tab of the Vehicle Mount until
it engages. (figure 3).
3. Place the suction cups on the
Vehicle Mount in an
appropriate location on your
windshield. Press firmly to
secure the Receiver in place.
(figure 3).
4. Connect the DC Power,
antenna and audio (if
required) to the appropriate
jacks. (figure 4).
INSTALLATION
4.
3.
2.
1.
