4
FUNCTIONS AND PARTS LIST
MPEG4 DVR Handheld Monitor -Front View
1 IR (infrared) LED: Emit invisible IR light to see in the dark.
2 CAMERA LENS
3 BRACKET HOLE: There is a hole on the top of the camera for ceiling
mounting and the bottom for other mounting solutions.
4 ANTENNA
5 LIGHT DETECTOR: CDS Sensor will automatically turn on the IR LEDs when
it gets dark.
6 MICROPHONE
7 POWER CONNECTOR
8 CHANNEL SWITCH (ON/ OFF)
9 POWER LED: Indicates that power is being fed to the camera.
GX5400: 2.4GHz Wireless Digital Video Recording System
