Component Location
Take a moment to familiarise yourself with the main components
of your product.
Front View
Automatic
Document Feeder
Document
Guides
Document
Input Tray
Document
Output Tray
Control Panel
(See page 1.6. SCX-
5312F. See page 1.9 for
SCX-5112.)
Paper Cassette
Front Cover
Release lever
Side Cover
Paper Guides
Bypass Tray
Scanner Module
