Getting Started
12
1
Connecting the Machine to the Host Using the Parallel Interface
Cable
Connect the machine to the host computer using a parallel interface cable com-
pliant with IEEE 1284 (supplied by you).
Follow these steps to connect the machine to the host computer.
A
Confirm that you have the correct cable.
B
Confirm that both the machine and a computer are turned off.
C
Plug the 36-pin end of the parallel cable into the parallel port at the right
side of the back cover of the machine.
Reference
See p.8 “Connecting the Machine” to confirm the position of the parallel
port.
D
Squeeze the wire clips on each side of the connector together until they
snap into place. The clips hold the cable securely in place.
E
Plug the other end of the parallel cable into the computer's parallel port.
