Woodstock W1784 - Manual (Page 15)

Model W1784 (Mfg. Since 2/07)
-13-
PARTS LIST
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 X1784001 CYLINDER 39 X1784039 L-BOLT
3 X1784003 BUMPER 40 X1784040 CYLINDER HEAD SEAT
4 XPORP050 O-RING 49.7 X 3.5 P50 41 X1784041 STAPLE HEAD COVER
5 X1784005 DRIVER 42 X1784042 STAPLE HEAD
6 XPRP07M ROLL PIN 6 X 20 43 X1784043 MAGAZINE
7 XPSS31M SET SCREW M5-.8 X 8 44 X1784044 STAPLE HEAD SCREW
8 X1784008 PISTON 45 X1784045 LOADER
9 X1784009 PISTON HEAD 46 X1784046 RIVET 4 X 8
10 XPORP012-5 O-RING 12.3 X 2.4 P12.5 47 X1784047 IDLER WHEEL
11 X1783011 O-RING 32 X 4.5 48 X1784048 LOADING SPRING
12 X1784012 SEALING SLEEVE 49 X1784049 KEEPER
13 X1783013 O-RING 12.8 X 1.8 50 XPORS003 O-RING 2.5 X 1.5 S3
14 X1784014 SEALING CAP 51 X1784051 SPRING LEVER
15 X1783015 O-RING 15.6 X 1.8 52 X1784052 COMPRESSION SPRING
16 X1784016 GUN BODY 53 X1784053 LEVER PIN
17 X1784017 GASKET 54 X1784054 STUD M8-1.25 X 10
18 X1784018 END CAP 55 X1784055 MAGAZINE PIN
19 XPCAP39M CAP SCREW M4-.7 X 20 56 XPRP05M ROLL PIN 5 X 30
22 X1784022 CYLINDER GASKET 57 X1784057 LOADING HANDLE
23 X1784023 SLEEVE GASKET 58 XPCAP95M CAP SCREW M5-.8 X 30
24 XPORP046 O-RING 45.7 X 3.5 P46 59 X1784059 RUBBER BUTTON
25 X1784025 PLUNGER 60 X1784060 BASE
26 XPLW02M LOCK WASHER 4MM 61 XPLW03M LOCK WASHER 6MM
27 XPCAP16M CAP SCREW M4-.7 X 16 62 XPCAP29M CAP SCREW M6-1 X 40
28 XPS56M PHLP HD SCR M4-.7 X 16 63 X1784063 BASE PLATE 1/2 IN FLOORING
29 X1784029 EXHAUST PORT 64 XPFH02M FLAT HD SCR M6-1 X 12
30 X1784030 CYLINDER COVER 65 X1783063 HAMMER
31 XPCAP09M CAP SCREW M5-.8 X 17 66 X1784066 AIR PLUG 1/4 NPT
32 XPORP025 O-RING 24.7 X 3.5 P25 67 X1784067 BASE PLATE 3/4 IN FLOORING
33 X1783033 WHACK CAP 68 X1784068 PISTON REPAIR KIT
34 XPW02M FLAT WASHER 5MM 69 XPAW04M HEX WRENCH 4MM
35 X1784035 BRACE 70 XPAW03M HEX WRENCH 3MM
37 XPLN04M LOCK NUT M8-1.25 71 X1784071 COMPLETE O-RING KIT
38 XPW01M FLAT WASHER 8MM 72 X1784072 SAFETY GOGGLES
