Assembly Section 3-4
FM84A 09/03
© 2004 Alamo Group Inc.
ASSEMBLY
ASSEMBL
Y
DRIVELINE ATTACHMENT - To Gearbox
1. Insert yoke onto splined shaft. Twist red collar on end yoke.
2. Slide yoke (with collar twisted) onto gearbox shaft.
3. Move yoke back and forth until collar clicks and locks the yoke in place.
