12_ setting up
3. Remove the door from the lower hinge 5 by lifting the door straight up 6 .
Removing the Fridge Door
1. With the door closed, remove the upper hinge cover 1 using a screwdriver.
2. Remove hinge screws 2 and the ground screw 3 by turning counter-clockwise, and take off
the upper hinge 4 . Be careful that the door does not fall on you as you are removing it
4
2
3
1
4. Remove the lower hinge 7 from the bracket 8 by gently lifting the lower hinge upwards.
