Sanyo POA-PN10 - Manual (Page 23)

23
Network Unit
OWNER’S MANUAL
Configure the network of computer
ENGLISH
Macintosh
This example explains how to set the following network address.
1
Select TCP/IP* 1 menu from the
[Apple] - [Control Panel] menu.
2
Select Ethernet from the "Connect
via" pull down menu and Manually
from the "Configure" pull down
menu of the TCP/IP Control Panel.
3
Enter the IP Address* 2 and Subnet
Mask.
4
Enter the Router Address.
✐ This setting is not needed if the net-
work does not provide the gateway
(router).
5
Close the setting window and save
the setting.
IP Address : 192.168.0.5
Subnet Mask : 255.255.255.0
Gateway Address : 192.168.100.1
*1 Select the "TCP/IP" item of the LAN card you use. If the "TCP/IP" item is not listed in the col-
umn, you need to install the TCP/IP protocol. For further information refer to the user's man-
ual of your computer.
*2 If the network already has the TCP/IP protocol set, enter with the same IP network number
for the IP address and Subnet mask.
