Specifications
64
Specifications
System/network
Protocol TCP/IP, ARP, ICMP, HTTP, FTP
(server/client), SMTP (client),
DHCP (client), DNS (client), NTP
(client), SNMP (MIB-2), RTP/
RTCP, PPPoE
Compression
Video compression format
MPEG4/JPEG (selectable)
Audio compression format
G.711/G.726 (40, 32, 24, 16 kbps)
Image size 640 Ч 480, 480 Ч 360, 384 Ч 288, 320
Ч 240, 256 Ч 192, 160 Ч 120
Maximum frame rate
MPEG4:30 fps (QVGA)
JPEG:30 fps (QVGA)
Web browser Internet Explorer Ver. 5.5 or 6.0
(Available OS: Windows 2000/ XP)
Computer environments
CPU: Pentium III, 1GHz or higher
(Pentium 4, 2 GHz or higher
recommended)
RAM: 256 MB or more
Display size: 1024 × 768
Maximum user access
MPEG4 mode: 10 users
JPEG mode: 20 users
Network security
Password (basic authentication), IP
filtering
Other functions
Motion detection, Image cropping,
Built-in clock, etc.
Camera
Image device NTSC
1/4 type interline transfer (Super
HAD CCD), 380,000 picture
elements
PAL
1/4 type interline transfer (Super
HAD CCD), 440,000 picture
elements
Effective picture elements
NTSC
768 (horizontal) × 494 (vertical)
PAL
752 (horizontal) × 582 (vertical)
Lens mount CS mount
Signal format NTSC/PAL
VBS: within 1.0 Vp-p ±5%, 75 ohms,
sync negative
Scanning NTSC
525 lines, 2:1 interlace
PAL
625 lines, 2:1 interlace
Synchronization
INT only
Horizontal resolution
480 TV lines (analog video)
Signal-to-noise ratio
50 dB (AGC OFF, Weight On) (analog
video)
Minimum illumination
0.9 lux (AGC ON, F1.0)
AGC On/Off switchable
Exposure control
AUTO iris
Electronic shutter
CCD Iris
White balance ATW
BLC On/Off switchable
Interface
Network port 10BASE-T/100BASE-TX (RJ-45)
I/O port 9 pin Mini DIN connector
Sensor input : make contact
Alarm output 1 and 2: 24 V AC/DC,
max., 1 A
(mechanical relay outputs
electrically isolated from the
camera)
Day/Night control input: ×1, 5 V DC
input
Day/Night control output: ×1, 5 V DC
output
Auto iris lens connector
DC servo
