– 27 –
APPENDIX
■ ■
Data transmission rate (baud rate)
Baud rate 3-1 3-2 3-3
150 bps OFF OFF OFF
300 bps OFF OFF ON
600 bps OFF ON OFF
1200 bps OFF ON ON
2400 bps ON OFF OFF
4800 bps ON OFF ON
9600 bps ON ON ON/OFF
■ DIP SW 4 (For serial interface type only)
Function DC1, DC3 Addressable mode *4 DC1, DC3
Switch invalid mode #1 #2 #3 #4 #5 #6 #7 #8 #9 #10 #11 #12 #13 #14 valid mode
4-1 ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
4-2 ON ON OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON OFF OFF
4-3 ON ON ON ON OFF OFF OFF OFF ON ON ON ON OFF OFF OFF OFF
4-4 ON ON ON ON ON ON ON ON OFF OFF OFF OFF OFF OFF OFF OFF
*4 The addressable mode is valid only when an optional RS-422A serial interface
is mounted.
