– 26 –
APPENDIX
■ DIP-SW 2
Switch Function ON OFF
2-1
Character code table See table below.
2-2
2-3 (Not used)
2-4 Setting the paper width
3.25-inch,
2.25-inch
3.0-inch
2-5 (Not used)
2-6
2-7 International character set See table below.
2-8
■ ■
Character code table (switches 2-1, 2-2)
Switch U.S.A. & Europe IBM #1 IBM #2 Japan
2-1 ON OFF ON OFF
2-2 ON ON OFF OFF
■ ■ International character set (Switches 2-6, 2-7 and 2-8)
Switch U.S.A. France Germany England Denmark Sweden Italy Spain
2-6 ON OFF ON OFF ON OFF ON OFF
2-7 ON ON OFF OFF ON ON OFF OFF
2-8 ON ON ON ON OFF OFF OFF OFF
■ DIP-SW 3 (For serial interface type only)
Switch Function ON OFF
3-1
3-2 Data transmission rate See next page
3-3
3-4
Auto cutting
Invalid Valid
control mode *3 (SP342)
3-5 Data composition DTR mode X-ON/X-OFF mode
3-6 Data word length 8-data bit 7-data bit
3-7 Vertical parity check No parity check Parity check
3-8 Parity Odd parity Even parity
*3 When a command is given to continuously feed paper over 7/6 inches in the
auto cutting control mode, the paper will be fully cut.
