28
REMOVING THE REFRIGERATOR DOORS
How to disassemble/assemble the Arctic Select Zone Door
1) Open the Arctic Select Zone Door.
3) Locate the eight phillips screws in the Arctic Select Zone. To lift the door up, unscrew the eight
phillips screws( ➀) four turns. Do not remove the screws (➀) out.
(You don’t need to unscrew the adjuster-phillips screw( ➁ )
2) Take out the box in the Arctic Select
Zone Door.
4) Remove the door carefully from the rail lifting up the
door with both hands.
To allow screw(
➀) heads to pass through the rail
holes.
5) Slide the rail carefully to the inside.
When you assemble the Arctic Select Zone Door, follow the contrary order.
NOTE
