Woodstock SHOP FOX W1686 - Manual (Page 33)

070 X1686070 POINTER
071 X1686071 POINTER MOUNT
072 X1686072 CABINET
073 X1686073 SPINDLE HOLDER
074 X1686074 SPINDLE HOLDER
075 X1686075 DOOR
076 X1686076 LOCK HANDLE
077 X1686077 SCALE
078 X1686078 RIVET
079 X1686079 OIL BREATHER
080 X1686080 KNOB 1 ⁄
4
" - 20 X 1"
081 X1686081 GASKET
082 X1686082 SWITCH
083 X1686083 CORD, SWITCH TO MOTOR
084 X1686084 POWER CORD
085 X1686085 STRAIN RELIEF
086 X1686086 MOTOR 1 HP
087 X1686087 WRENCH 35MM
088 X1686088 SPINDLE WRENCH
089 XPAW02M ALLEN ® WRENCH 2 MM
090 XPB24 HEX BOLT 3 /
8
" - 16 x 1 1 /
4
"
091 XPB18 HEX BOLT 3 /
8
" - 16 x 1"
092 XPLW04 LOCK WASHER 3 /
8
"
093 XPSS07 SETSCREW 1 /
4
" - 20 x 1 /
2
"
094 XPRP42M ROLL PIN 3 x 20mm
095 XPW02 FLAT WASHER 3 /
8
"
096 XPN02 HEX NUT 5 /
16
" - 18
097 XPSB38 CAP SCREW 10 - 32 x 3 /
8
"
098 XPB16 HEX BOLT 3 /
8
" - 16 x 1 1 /
2
"
099 XPN08 HEX NUT 3 /
8
" - 16
100 XPSB03 CAP SCREW 5 /
16
" - 18 x 1"
101 XPLW01 LOCK WASHER 5 /
16
"
102 XPSB16 CAP SCREW 3 /
8
" - 16 x 3 /
4
"
103 XPSB16 CAP SCREW 3 /
8
" - 16 x 3 /
4
"
104 XP6206 BEARING 6206 - 2RS
105 X1686105 SEAL 30 - 62 - 8
106 XPR38M SNAP RING 62mm
107 XP6205 BEARING 6205 - 2RS
108 XPSB39 CAP SCREW 5 - 40 x 1 /
2
"
109 XPRP05M ROLL PIN 5 x 30mm
110 XPK12M KEY 5 x 5 x 30mm
111 XPSS08 SETSCREW 5 /
16
" - 18 x 1 /
2
"
112 X1686112 DRAIN PLUG
113 XPN04 HEX NUT 5 /
8
" - 11
114 XPLW06 LOCK WASHER 5 /
8
"
115 XPB19 HEX BOLT 1 /
4
" - 20 x 1 /
2
"
116 XPLW02 LOCK WASHER 1 /
4
"
117 XPB03 HEX BOLT 5 /
16
" - 18 x 1"
118 X1686118 5 /
16
" FENDER WASHER
119 XPN13 HEX NUT 1 /
2
" - 13
120 XPSS29 SETSCREW 10 - 24 x 1 /
4
"
121 XPN03 HEX NUT 3 /
4
" - 16
122 XPS03 PHLP HD SCRW 10 - 24 x 1"
123 X1686123 MACHINE ID/WARNING
124 XLABEL01 SAFETY GLASSES 2" X 3"
125 X1686125 READ MANUAL WARNING
126 X1686126 ELECTRICITY WARNING
REF PART # DESCRIPTION REF PART # DESCRIPTION
