14 Elite 9 Installation Guide, Rev. B
Characteristics of ST410800 drives
N/ND W/WD
SCSI-2 Interface 1 Fast Fast & Wide
Multi-segmented cache
Physical 1,024 Kbytes 1,024 Kbytes
Available to user 960 Kbytes 960 Kbytes
Capacity
Unformatted 10,800 Mbytes 10,800 Mbytes
Formatted 2 9,090 Mbytes 9,090 Mbytes
Recording
Cylinders (user accessible) 4,925 4,925
Read/Write heads 27 27
Modulation RLL 1,7 code RLL 1,7 code
SCSI rates
Max burst transfer 10 Mbytes/sec 20 Mbytes/sec
Seek time 3
Average read 11 msec 11 msec
Average write 12 msec 12 msec
Disc rotation
RPM 5,400 5,400
Average latency 5.55 msec 5.55 msec
1 Can also be operated according to SCSI-1 protocol.
2 Standard factory units are formatted as follows:
512 data bytes per sector
9 spare sectors per cylinder
1 cylinder at the inner track reserved for spares
3 Not including on-board controller overhead.
