Getting Started
Connecting the Telephone and Modem
The main unit is equipped with a single modem port to connect the internal modem with a telephone wall jack. To use the
wall jack for both telephone and modem lines, purchase an additional RJ-11 phone cable and a "1-to-2" port adapter device
(splitter).
To connect the modem
1 Unplug the phone cable to your telephone from the wall jack and set aside.
2 Plug another phone cable (not supplied) into the modem port on the back of the main unit.
3 Plug the other end of the cable into the wall jack.
To connect the telephone and modem
1 Unplug the phone cable to your telephone from the wall jack.
2 Plug it into one of the ports on a "1-to-2" port adapter device (splitter) (not supplied) (1).
3 Plug one end of a second phone cable (not supplied) into the other port on the splitter device.
4 Insert the plug end of the splitter device into the wall jack.
5 Plug the other end of the second phone cable (2) into the modem port (3) on the back of the main unit.
