112

n

N

Upgrading Your VAIO Computer

9

Connect the SATA cables to the hard disk drives as follows:

!

Use of a commercially available SATA cable with the straight-head connector may damage the connector on the hard disk drive by being pulled out
when you replace the drive holder. We recommend you use Sony SATA cables exclusively designed for your computer.

10 Replace the front panel.

See Removing and Replacing the Main Unit Front Panel

(page 89)

for the detailed instructions.

Connect the internal SATA cables:

To the hard disk drives in:

PORT0 cable

Rightmost drive bay

PORT1 cable

Second drive bay from the right

PORT2 cable

Third drive bay from the right

PORT3 cable

Leftmost drive bay
