• 5 •

This converter uses a nonsinusoidal waveform.

Therefore, we do not recommend you use it to power the

following devices:

1. Switch mode power supplies

2. Linear power supplies

3. Class 2 transformers

4. Line filter capacitors

5. Shaded pole motors

6. Fan motors

7. Microwave ovens

8. Fluorescent and high intensity lamps (with a ballast)

9. Transformerless battery chargers

Doing so may cause the device to run warmer or overheat.

3. FASTENING THE CONVERTER TO A FLAT SURFACE

For convenience, your converter can be fastened to a flat

surface, horizontally or vertically. The area where the converter

is to be fastened must be dry, well ventilated and away from any

combustible material or fumes.

1. Turn off and disconnect the converter.

2. Place the back of the converter with the mounting bracket

against a secure and flat surface.

3. Attach the converter to the flat surface using corrosion-

resistant screws.

4. CONNECTING CONVERTER CABLES

The converter and power source must be in the OFF mode.

Make sure you connect your converter to a 12V

power supply only.

Converter connection:

1. Locate the positive and negative plastic terminals located on the

back of the converter and remove the terminal caps completely.

2. Install the positive (red) cable ring lug onto the positive (red)

terminal screw. Install the negative (black) cable ring lug onto

the negative (black) terminal screw. Tighten each terminal, so

that the cable cannot come loose.
