• 10 •

9. TROUBLESHOOTING

PROBLEM

REASON

SOLUTION

Red LED is on,

audible alarm

is on, and/or

converter does

not function.

Poor contact at

terminals.

Fuse blown.

Converter

shutdown.

Converter may

not be working

properly.

Unplug and reinsert the 12V

plug or check connections at

power supply.

See “IF THE Converter

FUSE BLOWS” section.

See “LED INDICATOR

AND SHUTDOWN

PROTECTION” section.

See Warranty and contact

Customer Service.

10. SPECIFICATIONS

Maximum Continuous Power ..........................................410 Watts

Surge Capability (Peak Power) .......................................820 Watts

No Load Current Draw .......................................................... <0.5A

Wave Form ......................................................Modified Sine Wave

Input Voltage Range..............................................10.5V-15.5V DC

Output Voltage Range ............................................. 120V ± 5% AC

Low Battery Alarm .....................................Audible, 11V ± 0.3V DC

Low Battery Shutdown ...........................................10.5V ± .3V DC

High Battery Shutdown ........................................15.5V ± 0.5V DC

Optimum Efficiency ................................................................. 85%

AC Outlet ..................................................... Two, NEMA 5-15 USA

USB Port .............................................................One, 5V DC 2.1A

Fuse .......................................................... Two, 25A (Spade Type)

Dimensions ............................................. 6.5" L x 4.13" W x 2.2" H

Weight .............................................................approximately 2 lbs.
