7
Using your Sunbeam StickMaster cont.
Using the chopper attachment (provided
with models SM6210 and SM8310)
1. Place the chopper bowl on a clean, level
surface.
2. Fit the stainless steel chopper blade into the
chopper bowl.
3. Place food into the chopper bowl.
4. Attach the lid onto the chopper and rotate
the lid in a clockwise direction until it locks
into position.
5. Insert the top part of the chopper lid into
the hole on the base of the motor housing
until you hear a click. See diagram 3.
6. Hold the container with one hand while
operating the switch with the other.
Using the whisk attachment (provided with
model SM8310)
1. Insert the whisk arm into the small hole on
the bottom of the whisk adaptor. See
diagram 4.
2. Fit the whisk adaptor into the hole on the
base of the motor housing until you hear a
‘Click’. See diagram 4.
Diagram 3
SPE ED CO NTR OL
Diagram 4
Press Eject
button to
release
Whisk
adaptor
Whisk arm
