– 26 –
10-1.General Specifications
(1) Printing method Direct line thermal printing
(2) Print speed Max. 1000 dots/sec. (125 mm/sec.)
(3) Dot density 203 dpi: 8 dots/mm (0.125 mm/dot)
(4) Printing width Max. 72 mm
(5) Roll paper Refer to chapter 5 for details on the recommended roll
paper.
Paper width:79.5±0.5 mm (57.5±0.5 mm when the
paper roll holder is used)
Roll diameter: ø83 mm or less
(6) Overall dimension 142 (W)
× 204 (D) × 132 (H) mm
(7) Weight Auto cutter model : 1.72 kg (without roll paper)
Tear bar model : 1.56 kg (without roll paper)
(8) Noise Approx. 49 dB (Auto cutter model)/48 dB (Tear bar model)
10. Specifications
204 mm
132 mm 142 mm
