– 13 –

4-1. Attaching the Holder Plate

(1) Attach the holding plate to the

printer. Then tighten the two screws
that were supplied to secure it in
place.

(2) Position the printer over the wall

bracket and then slide it downward
to set it in place.
The printer is fixed in place by inter-
locking the hook on the plate at-
tached to the bottom of the printer
with the hook connector on the
bracket. It is not necessary to secure
it further with screws. To purchase
a bracket, which is sold separately,
please contact your dealer.

(3) Push the cover open lever, and open

the printer cover.

(4) Insert the roll paper as shown.

4. Attaching the Accessories
