J-series knobs, Functions – Schlage Price Book 70A User Manual
Page 77
22
by
PRICE BOOK 70
Effective February 25, 2008
FUNCTIONS
Three Piece Assembly For Easy Installation
Screw Posts For Easy Installation
Door Preparations
2-1/8"
54 mm
1"
25 mm
2-1/4"
57 mm
2-3/8"
60 mm
1" dia.
25 mm
Brass Cylinder Plugs and Pins for Better Appearance and Durability
J-Series Knobs
Exploded View - J54 Byron
