9
JD SERIES DEADBOLTS
JD
SERIES
DEADBOL
TS
by
PRICE BOOK 70
Effective February 25, 2008
Table of Contents
Freight Weight ........................................................9
Functions ..............................................................10
Complete Locks ....................................................11
Standard Features
Certification
ANSI A156.5, 2001, Grade 3
Deadbolt Latch
Triple Option: 1" x 2-1/4", square corner and 1/4" round faceplates, drive-in latch,
1" housing diameter, 1" throw
Strike
1" x 2-1/4" round corner and radius corner, full lip
Backset
Adjustable for 2-3/8" or 2-3/4"
Cylinder
5-Pin, C keyway, keyed alike (KA4)
Door Range
1-3/8" - 1-3/4"
Keys
Two brass cut keys per lock, 5-pin, C section
Product Identification
JD 60
F
Suffix
F = UL Listed, available with JD60
Function
Lock Series
Finish Codes and Descriptions*
Code
Description
605 (US3)
Bright Brass
609 (US5)
Antique Brass
619 (US15)
Satin Nickel
620 (US15A)
Antique Pewter
625 (US26)
Bright Chrome
630 (US32D)
Satin Stainless Steel
716
Aged Bronze
*See Terms and Conditions for further finish details
by
BOX PACK - Deadbolt Freight Weight
Case
Average
Cubic
Case Dimensions (inches)
Lock Series
Functions
QTY
Wt/Case
Feet
Length
Width
Depth
JD60
24
35.85
.93
13.58
12.01
8.46
JD62
24
44.66
.93
13.58
12.01
8.46
JD80
24
21.04
.55
10.87
9.73
7.48
JD81
24
25.30
.58
12.28
10.35
7.87
JD
