13
JH,
JI
&
JT
SERIES
HANDLESETS
by
PRICE BOOK 70
Effective February 25, 2008
Table of Contents
Freight Weight ......................................................13
Functions ..............................................................14
Complete Locks ....................................................15
Standard Features
Certification
ANSI A156.5, 2001, Grade 3, Entry Handleset
Deadbolt Latch
Triple Option: 1" x 2-1/4", square corner and 1/4" round faceplates, and drive-in latch,
1" housing diameter, 1" throw
Spring Latch
Dual Option: 1" x 2-1/4", 1/4" round face plate and drive-in
Deadbolt Strike
1" x 2-1/4", round corner and radius corner, full lip
Latch Strike
1-5/8" x 2-1/4", radius corner, full lip
Backset
Adjustable for 2-3/8" or 2-3/4"
Cylinder
5-Pin, C keyway, keyed different (KD)
Door Range
1-3/8" - 1-3/4"
Keys
Two brass cut keys per lock, 5-pin, C section
Product Identification
JH 59
F
Suffix
F = UL Listed, available with JH59
Function
Lock Series
Finish Codes and Descriptions*
Code
Description
605 (US3)
Bright Brass
609 (US5)
Antique Brass
619 (US15)
Satin Nickel
620 (US15A)
Antique Pewter
625 (US26)
Bright Chrome
630 (US32D)
Satin Stainless Steel
716
Aged Bronze
*See Terms and Conditions for further finish details
by
JH SERIES HANDLESETS
BOX PACK - Handleset Freight Weight
Case
Average
Cubic
Case Dimensions (inches)
Lock Series
Functions
QTY
Wt/Case
Feet
Length
Width
Depth
JH60
4
20.24
.80
11.81
7.68
13.19
JH62
4
21.34
.80
11.81
7.68
13.19
JH193
4
16.06
.80
11.02
15.35
17.91
JH58
4
13.86
.80
11.81
7.68
13.19
JH59
24
26.77
1.20
16.54
13.39
8.27
JI58
24
30.36
1.56
21.18
17.80
6.38
JI
JI59
12
33.88
1.10
13.58
12.80
9.84
JI18
24
29.04
1.56
21.18
17.80
6.38
JI19
12
34.32
1.10
13.58
12.80
9.84
JT
JT58
20
27.72
1.83
14.96
13.39
14.17
JH
