6. ASSEMBLING AND INSTALLATION



Perform assembly work by following the procedure herein stated. Failing to

comply with the instructions can cause electric shock hazard.



Perform assembling as per this manual. Since this is a complex machine,

erroneous assembling can cause an electric shock, machine damage and or not
functioning as per specified performance.



When assembling, be sure to use plural persons. Depending on the assembly

work, there are some cases in which working by one person alone can cause
personal injury or parts damage.



Ensure that connectors are accurately connected. Incomplete connections can

cause electric shock hazard.



Be careful not to damage the wires. Damaged wires may cause electric shock

or short circuit or present a fire risk.



This work should be performed by the Location's Maintenance Man or

Serviceman. Performing work by non-technical personnel can cause a severe
accident such as electric shock. Failing to comply with this instruction can
cause a severe accident such as electric shock to the player during operation.



Provide sufficient space so that assembling can be performed. Performing

work in places with narrow space or low ceiling may cause an accident and
assembly work to be difficult.



To perform work safely and avoid serious accident such as the cabinet's

falling down, do not perform work in places where step-like grade differences,
a ditch, or slope exist.



Handle molded parts with care. Undue weight or pressure may cause them to

break and the broken pieces may cause injury.



To perform work safely and securely, be sure to prepare a step which is in

a secure and stable condition. Performing work without using the step can
cause violent falling down accidents.



Make sure that the GD cable connector is inserted parallel to the plug.

Improper insertion may cause damage to the connector and present a fire

INSTALLING THE POP AND THE POP CARD

SECURING IN PLACE(ADJUSTER ADJUSTMENT)

INSTALLING THE GD-ROM DRIVE(SETTING GD-ROM DISC)

POWER SUPPLY, AND EARTH CONNECTION

TURNING POWER ON

ASSEMBLING CHECK

When carrying out the assembling and installation, follow the following 6-item sequence.
