38
Superimposed Text Information
Chap
te
r 2
Pr
epa
ra
tio
n
s
f Operation mode
The field is divided into two blocks as shown below.
• Block A displays the operation mode.
• Block B displays the servo lock status or playback speed.
Displaying Supplementary Status
Information
When you set the setup menu item DISPLAY CONTROL
>SUB STATUS to other than “OFF” (see page 89), you
can view supplementary status information on the monitor
screen below the operating mode display area.
The following items of supplementary status information
are displayed depending on the setting of the menu item
SUB STATUS.
The following tables show the on-screen indications of
supplementary information and their meaning.
When the menu item SUB STATUS is set to “TC
MODE”:
Display Description
B1 The current menu settings are the same as the
settings in menu bank 1.
B2 The current menu settings are the same as the
settings in menu bank 2.
B3 The current menu settings are the same as the
settings in menu bank 3.
DF The current menu settings are the same as the
factory defaults.
No
display The current menu settings are different from all
of the above.
Display Operation mode
Block A Block B
DISC OUT Disc is not loaded.
LOADING Disc is being
loaded.
UNLOADING Disc is being
unloaded.
STANDBY OFF Standby-off mode
STOP Stop mode
NEXT Cuing up to the first
frame of the next
clip.
PREV Cuing up to the first
frame of the current
clip.
F.FWD Fast forward search
F.REV Fast reverse search
PLAY Playback mode
(servo unlocked)
PLAY LOCK Playback mode
(servo locked)
REC Record mode
(servo unlocked)
REC LOCK Record mode
(servo locked)
JOG STILL A still picture in jog
mode
JOG FWD Jog mode in
forward direction
JOG REV Jog mode in
reverse direction
A B
SHUTTLE STILL A still picture in
shuttle mode
SHUTTLE (Speed) Shuttle mode
VAR (Speed) Variable speed
mode
TOP 0001/xxxx Cuing up to the first
frame of the first
clip.
END xxxx/xxxx Cuing up to the last
frame of the last
clip.
PREROLL Cuing up during
preroll
Setting of menu item
SUB STATUS Items of supplementary
information displayed
TC MODE Operating mode of the internal
timecode generator
REMAIN Amount of free capacity on the
disc (in minute units).
CLIP NO Clip number
On-screen
indication Meaning
INT PRST FREE The internal timecode generator is
operating in FREE RUN mode.
INT PRST REC The internal timecode generator is
operating in REC RUN mode.
Display Operation mode
Block A Block B
T C R
P L A Y
0 0 : 0 4 4 7 . 0 7
L O C K
.
I N V A 1 3 4 2 T C S
Supplementary status information
