Hardware comparison chart – Smooth Fitness CE 7.4E User Manual
Page 6

SMOOTH CE 7.4E ELLIPTICAL TRAINER
www.smoothfitness.co.uk
6
HARDWARE COMPARISON CHART
Hardware chart:
For your convenience, we have identified the hardware used in the assembly of this product. This chart is provided to help
you identify those items that may be unfamiliar to you.
NO. DESCRIPTION QTY.
30
20 x 91 x M14mm Bolt
2
59
M8 x 45mm Bolt
4
74
M8 x 15mm Bolt
1
78
M8 x 65mm Bolt
2
88 M14
Nut
2
91
8mm Curve Washer
2
95
4 x 19mm Screw
4
97
4 x 15mm Screw
4
98
M8 CAP Nut
2
104
M6 x 20mm Screw
2
105
M6 x 12mm Screw
7
D M14
Spanner
1
E
5mm Allen Key
1
F
8mm
Allen Key
1
G 13/14mm
Spanner
1
H
Screw Driver
1
78
74
95
97
105
88
98
91
E
F
D
G
H
104
59
30
MILLIMETERS
