Instructions for the user
3.
DESCRIPTION OF CONTROLS
3.1
Front control panel
All the cooker controls and commands are on the front panel.
The user has only to press the central key
for 1/2 seconds to enable
use of the oven on first use or after a power blackout. (only for the main
oven)
DESCRIPTION OF SYMBOLS
FRONT LEFT-HAND
COOKING ZONE
MAIN OVEN
REAR LEFT-HAND
COOKING ZONE
AUXILIARY OVEN
GRILL
REAR RIGHT-HAND
COOKING ZONE
AUXILIARY OVEN
VARIABLE GRILL
FRONT RIGHT-HAND
COOKING ZONE
COOKING HOB CONTROL KNOB
Standard heating
The circle next to each knob indicates the cooking
zone it controls. To heat, turn the knob to the desired
position (1 to 9). Adjustment is continuous so that the
appliance also operates at any intermediate value. To
turn off, return the knob to 0.
