SEAL 44/62 - Manual (Page 25)

Application Processes 23
E
n
g
lis
h
6.5 Decaling without liner
Preparation:
Select the films that you will use on the top and bottom of the images, it is advisable to
use slightly wider width films compared to the print width. This way the print can be
trimmed with a border, so as to reduce waste, but be enough to leave a border. Place the
material rolls into the machine with the adhesive facing you. Web as follows:
Figure 24 Figure 25
Linerless films:
1. Pull the film down from the upper unwind position and place the film evenly over the
top roller.
2. Pull the film from the lower unwind position and stick them together on the top roller.
3. Press the laminates into the nip using the provided leader board.
4. Replace the infeed table.
5. ALWAYS INSTALL THE IMAGE GUIDE.
YOU ARE NOW READY TO FEED IMAGES.
