Application Processes 19
E
n
g
lis
h
6.2 Webbing the films
After the laminator has heated up;
• Remove the infeed table. If applicable, the infeed table can be stored temporarily on
the stand.
• Unroll the film on the top supply shaft, so that an adequate length is hanging over the
top roller (see figures 13 & 14). If necessary, release the supply shaft brake.
• If using a film with release liner, peel back liner and attach it to the wind-up tube.
Figure 13 Figure 14
No release liner With release liner
• When using a laminate on the bottom, repeat the above procedure for the bottom
supply-shaft.
• Stick the lower web on the upper web (figure 15, 16 or 17)
Figure 15 Figure 16
No release liner With release liner
