How Do I Connect USB Network Devices?
27
How Do I Connect USB Network Devices?
Connecting USB Devices
You must connect your USB devices for use with your cable modem gateway.
Professional installation may be available. Contact your local cable service
provider for further assistance
The following diagram illustrates one of the various USB network connection
options that are available to you.
T10458
Computer 1
POWER
12VDC
HPNA
CABLE
USB
ETHERNET
RESET
1234
Power
Supply
75 Coaxial Cable
120V AC
12V DC
