8
Getting started
Step 1.
Inspect package to insure that all parts & accessories are included.
Step 2.
Find a proper location for your new HDT-1/HDT-1X HD Radio Tuner
following the guidelines on table 1.1.
Step 3.
Connect the included or other external FM antenna to Figure 2, #13.
Step 4.
Connect the included or other external AM antenna to Figure 2, #14.
NOTE:
TO IMPROVE RECEPTION AND DECREACE INTERFEARANCE FROM
YOUR NEW HDT-1/HDT-1X PLACE THE AM LOOP ANTENNA AT
LEAST 50MM AWAY FROM UNIT.
Step 5.
Connect your new HDT-1/HDT-1X to your AV system using either the
RCA Connection or Optional SPDIF Connection (On HDT-1X Model
Only). Always connect to your AV system first, then to your new
HDT-1/HDT-1X Tuner.
NOTE WHICH INPUT YOU ARE USING WHEN CONNECTING THE
HDT-1/HDT-1X TUNER TO YOUR AV SYSTEM FOR LATER
REFERENCE.
a. Using RCA Cables
i. Connect included or premium RCA cables to your AV system.
ii. Connect opposite end of the included or premium RCA cables to
your new HDT-1/HDT-1X HD Radio Tuner to Figure 2, #15 & #16.
b. Using Optional SPDIF connection (On HDT-1X only). Always prevent
excessive bending of the optical cable as this may distort audio
and/ or cause damage to your AV system or HDT-1/HDT-1X HD
Radio Tuner.
i. Connect optical cable to your AV system according to the cables
manufacturers directions.
ii. Connect opposite end of the optical cable to your new
HDT-1/HDT-1X using connectors in Figure 2, #17
Step 6.
Connect the AC power cable to the HDT-1/HDT-1X using connector in
Figure 2, #18. Connect the opposite end into an AC outlet located near
the unit.
