Understanding the Component Location
These are the main components of your machine:
Front View
Rear View
Control Panel (See page 1.6)
Front Cover
Paper Tray (Tray 1)
Front Output Tray (Face down)
Document Input
Support
Automatic
Document Feeder
Toner Cartridge
Paper Output
Extension
Manual Feeder
Manual Feeder Guides
Document
Guides
Document
Output Tray
Optional Paper Tray
(Tray 2)
Paper Level
Indicator
Line Jack
EXT
.Jack
Power Switch
USB Connector
AC Power Cord Connector
EXT Jack
*
Line Jack
*
If your country has a different
telephone connection system,
this socket may be blocked.
Rear Output
Slot (Face up)
Rear Cover
Tray 2 Cable
Connector
Parallel Connector
