6_ Assembling the cleaner
Assembling the cleaner
Product accessories
carton contents
accessories
Empty carton. Find the parts shown above before disposing of packing materials.
A. Vacuum cleaner body
B. Handle
C. Hose
D. Extension Pipe wand
The accessories are packed on the cleaner.
E. Crevice tool
F. Mini turbo brush
G. Dusting brush/Upholstery brush
Ⓐ Ⓑ Ⓒ Ⓓ
Ⓔ Ⓕ Ⓖ
1
slide fully retracted extension wand into the handle until you hear a click.
2
slide fully retracted wand and handle into the slot on body until you hear a click.
Makes sure slot guides and inserts.
3
slide fully retracted hose into the handle until you hear a click.
4
Put hose into hose guide down the back of the vacuum cleaner.
slide fully connected hose with the inverter. 5
