Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
DLP is a registered trademark of Texas Instruments. BrilliantColor and DynamicBlack are trademarks of Texas Instruments.
Table of Contents
Features and Design . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . 3
To The Owner . . . . . . . . . . . . . . . . . . . . . 4
Safety Instructions . . . . . . . . . . . . . . . . . 5
Air Circulation 6
Installing the Projector in Proper Directions 7
Moving the Projector 8
Compliance . . . . . . . . . . . . . . . . . . . . . . . 9
Part Names and Functions . . . . . . . . . . 10
Front 10
Back 10
Terminals and Connectors 11
Side Control and Indicators 12
Side Control 12
Indicators 13
Remote Control 14
Remote Control Battery Installation 15
Remote Control Receivers and Operating Range 15
Wired Remote Control 15
Remote Control Code 16
Installation . . . . . . . . . . . . . . . . . . . . . . 17
Lens Installation 17
Positioning Projector 17
Picture Level and Pitch Adjustment 17
Lens Shift Adjustment 18
Terminals of Projector 19
Connecting to Computer 20
Connecting to Video Equipment 21
Attaching the Cable Cover 22
Connecting the AC Power Cord 23
Basic Operation . . . . . . . . . . . . . . . . . . 24
Turning On the Projector 24
Turning Off the Projector 25
How to Operate the On-Screen Menu 26
Menu Bar 27
Operating with Projector Control 28
Operating with Remote Control 30
Input Selection . . . . . . . . . . . . . . . . . . . 32
Input 32
Computer Input Source Selection 33
Video Input Source Selection 34
Computer Input . . . . . . . . . . . . . . . . . . 35
Computer System Selection 35
Auto PC Adjustment 36
Manual PC Adjustment 37
Image Level Selection 39
Screen Size Adjustment 40
Video Input . . . . . . . . . . . . . . . . . . . . . . 42
Video System Selection 42
Image Level Selection 43
Screen Size Adjustment 44
Picture Image . . . . . . . . . . . . . . . . . . . . 46
Image Adjustment 46
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Setting 49
Maintenance and Care . . . . . . . . . . . . . 62
Filter Instructions 62
Replacing the Filter Cartridge 63
Resetting the Filter Counter 64
Resetting the Scroll Counter 64
Lamp Management 65
Lamp Replacement 66
Optional Color Wheel Installation 68
Cleaning the Projection Lens 69
Cleaning the Projector Cabinet 69
Warning Indicators 70
Appendix . . . . . . . . . . . . . . . . . . . . . . . . 71
Troubleshooting 71
Menu Tree 74
Indicators and Projector Condition 77
Compatible Computer Specifications 80
List of Picture in Picture 82
Technical Specifications 83
Optional Parts 84
Configurations of Terminals 85
PIN Code Number Memo 86
Dimensions 87
Serial Control Interface 88
How to adjust multiple screens 90
