Star Tech Development TSP100 - Manual (Page 35)

– 32 –
10. Specifications
10-1. General Specifications
(1) Printing method Direct line thermal printing
(2) Print speed Max. 1000 dots/sec. (125 mm/sec.)
(3) Dot density 203 dpi: 8 dots/mm (0.125 mm/dot)
(4) Printing width Max. 72 mm
(5) Roll paper Refer to chapter 5 for details on the recommended roll paper.
Paper width:79.5±0.5 mm (57.5±0.5 mm when the paper roll
holder is used)
Roll diameter: ø83 mm or less
(6) Overall dimension 142 (W)
× 204 (D) × 132 (H) mm
(7) Weight Auto cutter model : 1.72 kg (without roll paper)
Tear bar model : 1.56 kg (without roll paper)
(8) Noise Approx. U Model
49 dB (Auto cutter model)
48 dB (Tear bar model)
PU Model
50 dB (Auto cutter model)
50 dB (Tear bar model)
Note: The noise measurements listed above were obtained
according to conditions established by this company. The
noise measurements may vary depending on the type of
paper used, type of printing, operating environment, and
power consumption mode.
204 mm
132 mm 142 mm
