4. connecting the usb/poweredusb cable to the pc, Caution – Star Tech Development TSP100 User Manual
Page 16
– 13 –
3-4. Connecting the USB/PoweredUSB Cable to the PC
3-4-1. U Model
Connect the USB interface cable to a USB port of your PC.
Note: The dialog shown below may appear on your PC
screen if your PC is running Windows 98 or Me,
and if you turn ON the power of the printer for the
first time while the PC and the printer are con-
nected with the USB cable. In this case, refer to the
software manual on the CD-ROM, in the following
directory: Documents folder.
3-4-2. PU Model
CAUTION
Make sure that the PC is turned off before connecting the PoweredUSB cable (Y cable) or
PoweredUSB cable (straight type).
Connecting the USB cable
Connecting the PoweredUSB cable (Y cable) or
PoweredUSB cable (straight type)
Connect the interface cable to a USB port of your PC.
