Page 4

BELT TENSION ADJUSTMENT
tension for the rotor drive is regulated by
the position of the set collar on
rotor clutch
rod.
a clearance of
between the
collar and
clutch rod clip will properly tension
this belt. Check this adjustment when the rotor
clutch is engaged.
Figure 7.
Belt
for transmission drive belt is reg-
ulated by the position of the wire clamp on the ex-
tension spring.
Figure 7.
BELT STOPS ADJUSTMENT
On the drive pulley side of the engine, belt
stops arc mounted as shown in Figure 9.
the rotor clutch and
clutch and check
clearance between belts and
stops. The belt
stops
be properly
when
clear-
ance is visible between
stops and the belts. To
adjust, loosen the hex capscrews and reposition the
stops to proper clearance. Retigbten hex capscrews
to hold stops in proper position. Refer to Figure 9.
OPERATION
Before attempting to start the engine or to op-
erate the Sno-Away, refer to the engine manufac-
turer’s owner’s manual for the proper fuel, oil, and
procedure for starting the engine.
operation of the rotor is controlled by the
rotor clutch. To engage the rotor clutch, raise the
foot pedal shown in Figure 9.
To disengage the
clutch, depress the foot pedal.
in mind that
the rotor will operate
the forward
travel of the Sno-Away, as long as the engine is run-
ning and the clutch is engaged. Exercise caution at
all times, and
attempt to remove snow or ice
from the
housing or discharge spout unless
the engine is stopped and rotor clutch is disengaged.
To stop the engine,
the throttle control lever
all the way to the shut-off position.
If the engine fails to shut-off after moving the
throttle control lever to the shut-off position, re-
position the “shorting-wire” to make contact with
the ignition shorting lever located on engine at end
of throttle cable.
The direction of travel of the Sno-Away is
controlled by the position of the transmission shift
lever. Refer to Figure 2. When shifting the trans-
mission, always release Touch-0-Matic control.
With the clutch disengaged, push down on the trans-
mission shift lever and
transmission will shift
