Planning Information
Integrated Model 700BR
Installation of an Integrated drawer unit
within framed cabinetry.
*Dimensions may vary.
Dimensions in parentheses are in
millimeters unless otherwise specified.
8
A) ALL REVEALS ARE 1/8" (3)
B) DRAWER RAILS ARE ATTACHED TO DRAWER FRONTS
C) BOTTOM RAIL MUST BE REMOVABLE
*DIMENSIONS MAY VARY
C
A
A
A
B
B
PANEL WIDTH
1
1
/
2
"
(38)
FRONT VIEW
SIDE VIEW
26
3
/
4
"
(679)
13
9
/
16
"
(345)
15
1
/
16
"
(383)
1
1
/
2
"
(38)
1
1
/
2
"
(38)
4"*
(102)
4"
(102)
34
1
/
2
"
(876)
*
24"
(610)
27"
(686)
SHADED AREA
INDICATES STATIONARY
STYLES AND RAILS
TOP VIEW
A
A
PANEL
CABINET DOOR
TO WALL
SUB-ZERO
UNIT
27"
(686)
24"
(610)
The illustration shows an Integrated drawer unit
installed within a framed cabinetry beaded inset
application.
IMPORTANT NOTE: Dimensions are based on a
1
/
8
" (3)
reveal. A reveal of up to
1
/
4
" (6) is possible, but panel
dimensions need to be adjusted accordingly.
F R A M E D C A B I N E T R Y – B E A D E D I N S E T A P P L I C A T I O N
