OVEN CONTROL PANEL

2

5

7

DISPLAY:

1. LED Display - Cooking time, power level, function

indicators are displayed.

KEYS:

2. Program Selection Keys - The unit is ready to

begin operation as soon as the heating time has
been programmed, using these ten keys (numbered
1 to 0). The time selected will be displayed, and
“counts down” after the process has begun.
For determining power output and cooking time dur-
ing programming.

3. Power Key - For entering the desired power output

into the unit memory.

4. Timer Key - For entering the desired cooking time

into the units memory.

5. Memory Key - For entering the desired power output

and cooking time.

6. Clear Key - For cancelling setting, interrupting the

setting process when a mistake has been made, or
stopping cooking before completion of the cooking
process.

7. Start key - For timer cooking. For start of pro-

grammed cooking.

6

1

3

4

6
