Installing the speakers on a
wall
The front speakers can be wall mounted, either
vertically or horizontally.
To mount the front speakers horizontally, follow
the procedure to install the center speaker.
1
Prepare screws (not supplied) that are
suitable for the hole on the back of
each speaker. See the illustrations
below.
2
Fasten the screws to the wall. The
screws should protrude 8 to 10 mm
(
11 /
32
to 13 /
32
inch).
3
Attach the supplied foot pads to the
speakers, and hang the speakers on
the screws.
Make sure that the hole on the back of the
speaker is in the right direction before
hanging the speaker.
Note
If you do not set the speaker correctly, the speaker
may fall down and cause injury.
4 mm (
5
/
32
inch)
more than 30 mm (1
3
/
16
inch)
Hole on the back of the front speakers
1 4.6 mm
(
3
/
16
inch)
2 10 mm
(
13
/
32
inch)
Hole on the back of the center speaker
and the surround speakers
4.6 mm
(
3
/
16
inch)
10 mm
(
13
/
32
inch)
2
1
1
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
280 mm
(11
1
/
8
inches)
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
For the front speakers
For the center speaker
280 mm
(11
1
/
8
inches)
For the surround speakers
8 to 10 mm
(
11
/
32
to
13
/
32
inch)
