Ballasts
139
ballasts
H a v e a s p e c i a l r e q u i r e m e n t ? V i s i t o u r w e b s i t e a t w w w . s a t c o . c o m
Electronic Ballasts
T4 4-Pin CF-L Socket and Electronic Ballast Combination
Featuring New TwistLock Protection
Lamp
Wattage(s)
Satco
Product
Number MOL
MOD Finish
Master /
Inner Pack
Mounting
Method
Wire
Spec
Lead
Length
13 80/1384 Short 13 Watt Socket 2.12” 2.00” x 2.37” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1325 Standard 13 Watt Socket 3.00” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1405 Standard 13 Watt Socket 2.37” 1.75” Ivory 200/25 Rt Angle Snap In UL1015 24”
80/1335 13 Watt Socket With Uno Ring 1.88” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
18 80/1385 Short 18 Watt Socket 2.12” 2.00” x 2.37” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1324 Standard 18 Watt Socket 3.00” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1406 Standard 18 Watt Socket 2.37” 1.75” Ivory 200/25 Rt Angle Snap In UL1015 24”
80/1336 18 Watt Socket With Uno Ring 1.88” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
26 80/1386 Short 26 Watt Socket 2.12” 2.00” x 2.37” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1383 Standard 26 Watt Socket 3.00” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
80/1382 26 Watt Socket With Uno Ring 1.88” 1.75” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
26-32-42 80/1323 26/32/42 Watt Socket 3.12” 2.50” Ivory 200/25 1/8” IPS Hickey UL1015 24”
C-UL Listed for Indoor/Outdoor applications Minimum Starting Temp -20 C / -4 F
26 - 32 80/1331 26W/32W Dimmer Socket 3.25” 3.75” Ivory 50/25 1/8” IPS Hickey UL1015 36”
C-UL Listed for indoor applicatons
Dimmer sockets are for Table and Floor Lamp Applications Only
Dimmer Control, and Harp Saddle are integral to the socket
120v 60Hz operation
3 Year Warranty
(Replacement only)
